Programmable DC Power Supply

BWDCP Series ( 1KVA ~ 480KVA )

For Applications

  • Communication & Broadcasting Station
  • New energy R&D
  • Electrical Engineering & Components Aging
  • Industrial Control Equipment
    & DC Motor Test
  • Cold-started heater test
  • Single-crystal furnace
    heating system, etc.
Frequency Converter

Main Features

  • Small volume, light weight
  • Memory stores 9 group data
    (volt/Amps) for easily recall
  • Overvoltage and overcurrent
    protection can be set according
    to customers’ requirement.
  • RS232/RS485 Modbus.

Blue Whale BWDCP series programmable DC Power Supply is one of the most popular adjustable DC power supplies designed to change AC power to DC Power.BWDCP is able to provide output voltage up to 1200V and current up to 1000A with digital display.It can be remote controlled and operated by computer.

Technical Specification

Capacity

7.5kW

15kW

30kW

60kW

120kW

240kW

360kW

480kW

Working technology

Switching -PWM

INPUT

Phase

3φ4W

Voltage

380V±10%

Frequency

50HZ±10%

OUTPUT

Voltage

Current

300VDC

25A

50A

100A

200A

400A

800A





600VDC

12.5A

25A

50A

100A

200A

400A

600A



900VDC

7.5A

17A

34A

68A

136A

272A

400A

800A

1200VDC

4A

8A

25A

50A

100A

200A

300A

400A

Ripple

1%FS

Load  Regulation

±1%FS

Voltage Resolution

Vo<1000:0.1V;Vo≥1000V:1V

Current Resolution

Io<1A:0.001A;         100A>Io≥10A:0.01A;        1000A>Io≥100A:0.1A;     Io≥1000A:1A。

kW Resolution

0.1W

LED Display

Volt、Amps、Watt、Time

Setting  mode

CV

10%-100% rated voltage

CC

10%-100% rated current

Setting  accuracy

Voltage

±1%

Current

±1%

Measuring   accuracy

Voltage

0.5%FS+5dgt

Current

0.5%FS+5dgt

Wattage

0.5%FS+5dgt

Memory

store 9 group data(voltage/current)for easily recall

I-LIM Set

O-Max Current(output cut off when exceed max current)

V-LIM Set

O-Max Voltage(output cut off when exceed max current)

Protection

Over Voltage, Over Current,Over Temp,Short Circuit

 Cooling

exhaust fans

Environment

0-40℃   20-80%RH(non condensation)

Weight(Kg)

50

100

150

300

750

1000

1800

2500

W×H×D(mm)

430×360×550

550×700×700

550×1100×700

600×1580×1000

1260×1580×1000
